Introdução ao produto
|
Materiais | A norma ASTM A403 WP304,A403 WP304L;A403 WP316,A403 WP316L,A403 WP321;A182 F304,304L,316,316L,904L |
| Normas de fabrico |
A norma ASME/ANSI B16.9, MSS-SP-43 JIS B2311/2220 DIN2615/2616/2617 ISO 3419, ISO 5251 |
|
| Espessura da parede | SCH5-STD-SCH XXS, etc. | |
| Diâmetro exterior |
1/2'-48' ((Butt soldagem, sem costura) |
ASME B16.9
| Tamanho nominal | Diâmetro externo em Bevel | Do centro ao fim | ||
| DN | NPS | OD1 × OD2 | C | M |
|
15 |
1/2 |
21.3 |
25 | 25 25 25 |
|
20 |
3/4 |
26.7 26.7x21.3 26.7x17.1 |
29 | 29 29 29 |
| 25 25×20 25×15 |
1 |
33.4 |
38 | 38 38 38 |
| 32 32×25 32×20 32×15 |
1 1/4 1 1/4 x 1 1 1/4 x 3/4 1 1/4 x 1/2 |
42.2 |
48 | 48 48 48 48 |
| 40 40×32 40×25 40×20 40×15 |
1 1/2 1 1/2 x 11/4 1 1/2 x 1 1 1/2 × 3/4 1 1/2 × 1/2 |
48.3 48.3x42.2 48.3x33.4 48.3x26.7 48.3x21.3 |
57 | 57 57 57 57 57 |
|
50 50×40 |
2 2 x 1 1/2 2 x 1 1/4 2x1 2×3/4 |
60.3 60.3x48.3 60.3x42.2 60.3x33.4 60.3x26.7 |
64 | 64 60 57 51 44 |
| 65 65×50 65×40 65×32 65×25 |
Dois e meio Dois e meio por dois. 2 1/2 x 1 1/2 2 1/2 x 1 1/4 2 1/2 x 1 |
73.0 73.0 x 60.3 73.0×48.3 73.0x42.2 73.0 x 33.4 |
76 | 76 70 67 64 57 |
| 80 80×65 80×50 80×40 80×32 |
3 3 × 2 1/2 3 × 2 3 x 1 1/2 3 x 1 1/4 |
88.9 88.9x73.0 88.9x60.3 88.9x48.3 88.9x42.2 |
86 | 86 83 76 73 70 |
|
90 90×40 |
3 e meio 3 1/2 × 3 3 1/2 × 2 1/2 3 1/2 x 2 3 1/2 x 1 1/2 |
101.6 101.6x88.9 101.6x73.0 101.6x60.3 101.6x48.3 |
95 | 95 92 89 83 79 |
| 100 100 × 90 100×80 100×65 100×50 100×40 |
4 4×3 1/2 4×3 4×2 1/2 4×2 4×1/2 |
114.3 114.3x101.6 114.3x88.9 114.3x73.0 114.3x60.3 114.3x48.3 |
105 | 105 102 98 95 89 86 |
ASME B16.9
| Tamanho nominal | Diâmetro externo em Bevel | Do centro ao fim | ||
| DN | NPS | 0D1XOD2 | C | M |
| 125 125×100 125×90 125×80 125×65 125×50 |
5 5×4 5×3 1/2 5×3 5×2 1/2 5×2 |
141.3 141.3x114.3 141.3x101.6 141.3x88.9 141.3x73.0 141.3x60.3 |
124 | 124 117 114 111 108 105 |
| 150 150×125 150×100 150×90 150×80 150×65 |
6 6×5 6×4 6×3 1/2 6×3 6×2 1/2 |
168.3 168.3x141.3 168.3x114.3 168.3x101.6 168.3x88.9 168.3x73.0 |
143 | 143 137 130 127 124 121 |
| 200 200×150 200×125 200×100 200×90 |
8 |
219.1 219.1 x 168.3 219.1 x 141.3 219.1 x 114.3 219.1 x 101.6 |
178 | 178 168 162 156 152 |
| 250 250×200 250×150 250×125 250 × 100 |
10 10×8 10×6 10×5 10 × 4 |
273.0 273.0 x 219.1 273.0 x 168.3 273.0 x 141.3 273.0×114.3 |
216 | 216 203 194 191 184 |
| 300 300×250 300×200 300 × 150 300×125 |
12 12 × 10 12×8 12 × 6 12×5 |
323.8 323.8x273.0 323.8 x 219.1 323.8 x 168.3 323.8x141.3 |
254 | 254 241 229 219 216 |
| 350 350×300 350 × 250 350×200 350 × 150 |
14 14×12 14×10 14 × 8 14 × 6 |
355.6 355.6x323.8 355.6 x 273.0 355.6 x 219.1 355.6 x 168.3 |
279 | 279 270 257 248 238 |
| 400 400×350 400×300 400×250 400×200 400×150 |
16 16×14 16×12 16 × 10 16×8 16 × 6 |
406.4 406.4x355.6 406.4x323.8 406.4x273.0 406.4 × 219.1 406.4x168.3 |
305 | 305 305 295 283 273 264 |
